Hot
ViaSat-10
$399.00
The ViaSat-10 is a Class I Div 1, magnetic-mount, satellite vibration monitoring device with built-in solar panel and batteries, ideal for monitoring the status of pumpjacks, compressors, switches, and more. ViaSat-10 is a satellite-based solution that works anywhere, and is ideal for locations with no cellular coverage.
- Satellite monitoring for Pumpjacks, Compressors, Generators, Motors, Pumps, Rental Units, Run Status, and More
- Vibration Sensor, 2 Digital Inputs, GPS
- Alarm Callout / Alarm Notifications via SMS, Email, and / or Voice Messages
- Escalating call lists can be set up to notify available staff of shutdowns
- Built-in Solar Panel and rechargeable NiMH Battery
- Class I, Division 1, Groups A-D, T4
- Temperature: -40˚ C to +65˚ C
- Magnetic Mount Option
Description
The ViaSat-10 is a Class I Div 1, magnetic-mount, satellite vibration monitoring device with built-in solar panel and batteries, ideal for monitoring the status of pumpjacks, compressors, switches, and more. ViaSat-10 is a satellite-based solution that works anywhere, and is ideal for locations with no cellular coverage.
- Satellite monitoring for Pumpjacks, Compressors, Generators, Motors, Pumps, Rental Units, Run Status, and More
- Vibration Sensor, 2 Digital Inputs, GPS
- Alarm Callout / Alarm Notifications via SMS, Email, and / or Voice Messages
- Escalating call lists can be set up to notify available staff of shutdowns
- Built-in Solar Panel and rechargeable NiMH Battery
- 8.26 cm x 17.78 cm x 2.86 cm
- Class I, Division 1, Groups A-D, T4
- Class I, Zone 0, AEx ia IIC T4 Ga
- ATEX/IECEx II 1 G, Ex ia IIC T4 Ga
- Temperature: -40˚ C to +65˚ C
- Magnetic Mount Option
Additional information
| Weight | .5 kg |
|---|---|
| Dimensions | 20 × 9 × 4 cm |
| Communication Type |
Satellite |
| Mounting |
Magnetic |
| Certification |
Class I Div 1 |
| Interface |
Built-In Vibration ,Digital Input |
